      CB7000 Corrugated Bundler Automatic Strapping Machine

      How do you avoid damage to corrugated across your supply chain? It starts with having the right bundling equipment to unitize product quickly, efficiently and securely. Equipment that works as hard as you do.

      That’s where Greenbridge comes in.


      • Full‑color touch screen
        Intuitive, easy to use interface.
      • Robust, compact mechanical strapping head
        The latest DC, German‑made brushless motor technology provides the industry’s highest level of accuracy + reliability.
      • Siemens PLC control
        Provides easy adjustments, TEACH‑IN programming + troubleshooting guides.
      • Free access to strap guides
        No tools needed to access strap guides.
      • Patented jammed‑strap ejection device
        Makes it easy to remove jammed strap and get back to work.
      • Full‑width pneumatic press
        Provides the highest reliability and stability.
      • Multiple strap function
        For single, double, continuous strapping or transit mode.
      • Variable Conveyor Speed
        Fully automatic operation with a variable conveyor.
      • Strap end ejector
        Eject end of strap from the inlet of strap feeding. Easy to clean + get the machine ready for next coil of strap.
      • Adjustable table height
        Adjusts from 27.5” to 39”
      Arch Sizes 65” (W) x 17” (H)
      49” (W) x 17 (H)
      Cycle Rate Up to 33 bundles per minute (single strap)
      Up to 20 bundles per minute (double strap)
      Strap Width 5mm, 6mm, 9mm polypropylene strap
      Strap Tension 2 to 70 lbs.
      Minimum Bundle Size 11” (L) x 8” (W) x 3/3” (H)
      Bundle Weight Max 88 lbs.
      Transport Speed 49 to 196 feet per minute
      Electrical Requirements 220V, 380V, 400V, 50/60Hz 3 Phase
